Casting ability

Technical indicators

Titanium alloy castings

Aluminum alloy castings

Minimum wall thickness

0.8mm

1.5mm

Biggest dimension

2400mm*2000mm*1500mm

2400mm*1700mm*1700mm

Weight

0.005kg~1000kg

0.005kg~1500kg

Surface roughness

Ra3.2~6.3μm

Ra3.2~6.3μm

Laser welding ability

Laser power

IPG  6KW(Fiber laser)

Equipment accuracy

±0.05mm

Processing Scope 1

6000mm(L)×2000mm(W)×1500mm(H)

Processing Scope 2

φ1400mm×4000mm

Weldable materials

Various materials such as titanium alloy, aluminum alloy, high-temperature alloy, copper alloy, steel, etc

Weld thickness

0.5mm-8mm

Spinning forming ability

Spinning range

Φ150~Φ600mm

Biggest length

3000mm(Positive rotation)4000mm(Reverse rotation)

Spinning material

Various materials such as aluminum alloy, alloy steel, stainless steel, high-strength steel, etc

Maximum double center distance during spinning

4000mm

Standard followed

GB/T 3620.1-2016

Designation and composition of Titianium and Tianium Alloys

GB/T 3621-2022

Titianium and Titanium alloy plate and sheet

ASTM B367-13

Standard Specification for Titanium and Titanium Alloy Castings

ASTM B348-13

Standard Specification for Titanium and Titanium Alloy Bars and Billets
